IRISLIB database
|
|
|
IRISLIB database
|
|
Renders the XSLT stylesheet that displays a ZEN report. More...
Public Attributes | |
| Encoding | |
| More... | |
| Indent | |
| More... | |
| PreserveSpace | |
| More... | |
| StripSpace | |
| More... | |
| name | |
| This property must match the name of the outermost tag of the report data. More... | |
| pageNumberFormat | |
| Allow setting page number format: More... | |
| parentClass | |
| More... | |
| primaryGroup | |
| Primary outer sort group name that XSL:for-each statement will work with. More... | |
| primaryGroupifxpath | |
| Primary outer sort group name ifxpath condition to determine if a group iteration should be. More... | |
| sectionName | |
| More... | |
| terminateIfEmpty | |
| Terminate if empty. More... | |
| title | |
| Report title. More... | |
| writingMode | |
| writing-mode XML attribute. More... | |
 Public Attributes inherited from childrenNode | |
| children | |
| More... | |
| parent | |
| More... | |
| xpath | |
| More... | |
| Public Attributes inherited from node | |
| class | |
| Specifies the node's style class. More... | |
| htmlstyle | |
| same as style only HTML only More... | |
| level | |
| use to pass down result set from table when table uses sql to generate itself More... | |
| selectstylecond | |
| list of conditions - true one at index i selects style More... | |
| selectstylelist | |
| list of styles - picked by first true index i in list of conditions More... | |
| style | |
| The style string is given in the form "attribute1:value1;attribute2:value2;...",. More... | |
| stylecall | |
| stylecall - name of xsl:template to call to output style attributes More... | |
| styleparamNames | |
| for each name here an xsl:with-param is generated with its name attribute set from here More... | |
| styleparams | |
| list of xpaths, xpath function calls, and XSLT function calls. More... | |
| tag | |
| Calculated property that contains the tag name of the node. More... | |
| template | |
| Specifies the template that can be used to add children to the node. More... | |
| width | |
| Specifies the width of the element within its containing object (page, table cell, etc.) More... | |
| withinSmallmultiple | |
| used to flag table or item, etc., as being under a small mutiple More... | |
| xmlnamespace | |
| We use these to record namespace and namespace prefix for qualified name. More... | |
| xmlnamespaceprefix | |
| More... | |
| xpath | |
| More... | |
| xslfostyle | |
| same as style only XSL-FO only More... | |
| Public Attributes inherited from controller | |
| applyLevel | |
| More... | |
| ifexpression | |
| More... | |
| ifxpath | |
| More... | |
| includeColIfExpression | |
| More... | |
| includeColIfXPath | |
| More... | |
| includeColUnlessExpression | |
| More... | |
| includeColUnlessXPath | |
| More... | |
| unlessexpression | |
| More... | |
| Public Attributes inherited from common | |
| composite | |
| @qualifier final For components that are created as part of a composite(template component, More... | |
| id | |
| This is a unique identifier that is used to distinguish this object. More... | |
Additional Inherited Members | |
| Public Member Functions inherited from RegisteredObject | |
| _.Library.Status | OnAddToSaveSet (_.Library.Integer depth, _.Library.Integer insert, _.Library.Integer callcount) |
| This callback method is invoked when the current object is added to the SaveSet,. More... | |
| _.Library.Status | OnClose () |
| This callback method is invoked by the <METHOD>Close</METHOD> method to. More... | |
| _.Library.Status | OnConstructClone (_.Library.RegisteredObject object, _.Library.Boolean deep, _.Library.String cloned) |
| This callback method is invoked by the <METHOD>ConstructClone</METHOD> method to. More... | |
| _.Library.Status | OnNew () |
| This callback method is invoked by the <METHOD>New</METHOD> method to. More... | |
| _.Library.Status | OnValidateObject () |
| This callback method is invoked by the <METHOD>ValidateObject</METHOD> method to. More... | |
| Public Member Functions inherited from Adaptor | |
| _.Library.Status | XMLExport (_.Library.String top, _.Library.String format, _.XML.Namespaces namespaces, attrs, _.Library.String createId, _.Library.String typeAttr, oreflist, idlist, _.Library.String initialIndent, _.Library.Boolean local, _.Net.MIMEPart mimeAttachments) |
| Serialize an XML enabled class as an XML document and write. More... | |
| _.Library.Status | XMLExportToStream (_.Stream.Object export, _.Library.String top, _.Library.String format, _.XML.Namespaces namespaces, attrs, _.Library.String createId, _.Library.String typeAttr, oreflist, idlist, _.Library.String initialIndent) |
| Serialize an XML enabled class as an XML document and appends it to a stream. More... | |
| _.Library.Status | XMLExportToString (_.Library.String export, _.Library.String top, _.Library.String format, _.XML.Namespaces namespaces, attrs, _.Library.String createId, _.Library.String typeAttr, oreflist, idlist, _.Library.String initialIndent) |
| Serialize an XML enabled class as an XML document and write it to a string. More... | |
| Static Public Member Functions inherited from Adaptor | |
| _.Library.Status | XMLDTD (_.Library.String top, _.Library.String format, _.Library.Boolean input, dtdlist) |
| Write the DTD to the current device for this XML enabled class serialized as. More... | |
| _.Library.RegisteredObject | XMLNew (_.XML.Document document, _.Library.Integer node, _.Library.RegisteredObject containerOref) |
| Get an instance of an XML enabled class. More... | |
| _.Library.Status | XMLSchema (_.Library.String top, _.Library.String format, _.Library.String namespacePrefix, _.Library.Boolean input, _.Library.Boolean refOnly, schema) |
| Write an XML Schema fragment to the current device which describes an XML enabled class and dependent classes. More... | |
| _.Library.String | XMLSchemaNamespace () |
| Get the namespace to which this class belongs for use in schema generation. More... | |
| _.Library.Status | XMLSchemaType (_.XML.Schema schemaInstance, _.XML.Node node, _.Library.String top, _.Library.Boolean encoded, _.Library.Boolean summary, _.Library.Boolean input, _.Library.Boolean refOnly) |
| Add a complexType to the schema that is respresented by an <class>XML.Schema</class> instance. More... | |
| Static Public Attributes inherited from node | |
| NAMESPACE = None | |
| XML namespace used for Zen Report display definitions. | |
| XMLIGNOREINVALIDATTRIBUTE = None | |
| By setting this to 0, we disallow use of invalid attribute names in Zen Report XML documents. | |
| Static Public Attributes inherited from common | |
| NAMESPACE = None | |
| XML namespace used for Zen Report display definitions. | |
| XMLFORMAT = None | |
| If XMLFORMAT="Literal", then only support for literal format import and export is generated. More... | |
| Static Public Attributes inherited from RegisteredObject | |
| CAPTION = None | |
| Optional name used by the Form Wizard for a class when generating forms. More... | |
| JAVATYPE = None | |
| The Java type to be used when exported. | |
| PROPERTYVALIDATION = None | |
| This parameter controls the default validation behavior for the object. More... | |
| Static Public Attributes inherited from Adaptor | |
| ATTRIBUTEQUALIFIED = None | |
| ATTRIBUTEQUALIFIED controls the format of exported XML by controlling whether attributes. More... | |
| ELEMENTQUALIFIED = None | |
| ELEMENTQUALIFIED controls the format of exported XML. More... | |
| NAMESPACE = None | |
| NAMESPACE specifies the XML namespace to be used when projecting the. More... | |
| SUPPRESSTYPEPREFIX = None | |
| SUPPRESSTYPEPREFIX allows the type name that refers to this class. More... | |
| XMLDEFAULTREFERENCE = None | |
| XMLDEFAULTREFERENCE specifies the default value of the XMLREFERENCE property parameter. More... | |
| XMLENABLED = None | |
| If this parameter is true then XML-enabling methods. More... | |
| XMLFORMAT = None | |
| The XMLFORMAT parameter controls the generation of the XMLExport and XMLImport. More... | |
| XMLIGNOREINVALIDATTRIBUTE = None | |
| The XMLIGNOREINVALIDATTRIBUTE parameter allows the programmer to control handling of unexpected. More... | |
| XMLIGNOREINVALIDTAG = None | |
| The XMLIGNOREINVALIDTAG parameter allows the programmer to control handling of unexpected. More... | |
| XMLIGNORENULL = None | |
| XMLIGNORENULL allows the programmer to override the default XML handling. More... | |
| XMLINCLUDEINGROUP = None | |
| XMLINCLUDEINGROUP allows the programmer to control whether a class is included. More... | |
| XMLINHERITANCE = None | |
| If the XMLINHERITANCE parameter is set to "LEFT", then in the case of multiple. More... | |
| XMLNAME = None | |
| This parameter provides the default XMLNAME for the class. More... | |
| XMLNIL = None | |
| The XMLNIL class parameter controls the use of xsi:nil by XMLExport. More... | |
| XMLNILNOOBJECT = None | |
| The XMLNILNOOBJECT parameter allows creation of an object to be skipped for elements. More... | |
| XMLPREFIX = None | |
| The XMLPREFIX parameter controls the prefix to be used for the XML namespace that. More... | |
| XMLSEQUENCE = None | |
| If the XMLSEQUENCE = 1, then the order of the XML elements must match the. More... | |
| XMLSUMMARY = None | |
| The summary fields to be used when an object is referenced are specified. More... | |
| XMLTYPE = None | |
| This parameter provides the default XMLTYPE for the class. More... | |
| XMLUNSWIZZLE = None | |
| If the XMLUNSWIZZLE parameter is set to 1, then single object. More... | |
| XMLUSEEMPTYELEMENT = None | |
| If the XMLUSEEMPTYELEMENT parameter is set to 1, then the empty element shorthand (<tag>) More... | |
Renders the XSLT stylesheet that displays a ZEN report.
| Encoding |
| Indent |
| PreserveSpace |
| StripSpace |
| name |
This property must match the name of the outermost tag of the report data.
In the case of ZEN generated data, this attribute must match the name attribute of the <report< tag in the ReportDefinition XData block.
| pageNumberFormat |
Allow setting page number format:
use i or I for roman use a or A for alphabetic use 1 for numeric
| parentClass |
| primaryGroup |
Primary outer sort group name that XSL:for-each statement will work with.
| primaryGroupifxpath |
Primary outer sort group name ifxpath condition to determine if a group iteration should be.
included and a page sequnce generated
| sectionName |
| terminateIfEmpty |
Terminate if empty.
| title |
Report title.
| writingMode |
writing-mode XML attribute.
It has the following possible values. Note that not all XSL-FO renderers will support all possible values.
lr-tb Text are written left-to-right and top-to-bottom (normal "alphabetic" text)
rl-tb Text are written right-to-left and top-to-bottom (Arabic and Hebrew text)
tb-rl Text are written top-to-bottom and right-to-left (Chinese and Japanese text)
lr Same as lr-tb
rl Same as rl-tb
tb Same as tb-rl
inherit
