Inheritance diagram for SQLQuery:

[legend]

Collaboration diagram for SQLQuery:

[legend]

Public Attributes
	CompileTime
	Number of Seconds it takes to compile the query. More...

	CursorName
	What is the name of the cursor for this SQL Statement. More...

	Hash
	hash the SQL so we can match incoming SQL with already stored Stats More...

	ImportSchema
	ImportSchema is used in generated code to handle sql statements that have unqualified table names. More...

	InternalQueryText
	More...

	NameSpace
	What NameSpace the SQL was generated in. More...

	QueryText
	Store the first 15000 charactors of the SQL Query in this field. More...

	QueryType
	Is the Query an INSERT UPDATE DELETE or SELECT query. More...

	RoutineName
	What Routine is the SQL generated in. More...

	RunCount
	Number of times this query has be executed. More...

	SQLIndexHash
	Internal unique statement hash used as the ID for the SQL Statement Index. More...

	SQLStatsPointer
	More...

	details
	Do we have level 3 stats for this query. More...

_.Library.String	Export (file, delim, exportPlan)

_.Library.Status	clearSQLQuery (_.Library.String ns, _.Library.String rtn, _.Library.Integer ph3, _.Library.Integer clearErrs, _.Library.Integer returnType, _.Library.RawString ptInfo)

_.Library.Status	exportSQLQuery (file, format, silent, exportPlan, _.Library.RawString conds, _.Library.RawString ptInfo, bcFlag)

_.Library.Status	purgeSQLQuery (_.Library.String ns, _.Library.String rtn, _.Library.Integer ph3, _.Library.Integer clearErrs, _.Library.Integer returnType, _.Library.RawString ptInfo)
	Entry Point providing new functionality to delete Backward-compatible data: More...

_.Library.String	version ()
	Provide the current version for the SYS.PTools.SQLQuery class/section of the Performance Tools (PTools) Application.

Additional Inherited Members
Static Public Member Functions inherited from FileCreation
	CSVtabHead (metadata, delim)
	CSV Table Header.

	CSVtabRow (metadata, delim)
	CSV Table Data Row.

	DLMtabHead (metadata, delim)
	DLM Table Header.

	DLMtabRow (metadata, delim)
	DLM Table Data Row.

	HTMLtabHead (aTag, title, metadata)
	HTML Table Header.

	HTMLtabRow (metadata)
	HTML Table Row.

	TXTtabHead (metadata, delim)
	Text Table Header.

	TXTtabRow (metadata, delim)
	Text Table Data Row.

	XMLcolAuto ()
	XML Column AutoFit Width Element.

	XMLcolWidth (width)
	XML Column Width Element.

	XMLrowHeader (metadata)
	XML Header Row Element.

	XMLsheet (name)
	XML Worksheet Element.

	XMLsort (sortColList, sortOrderList)
	XML Sorting Element.

	XMLtabRow (metadata)
	XML Table Data Row Element.

	XMLtable (colCnt, rowCnt)
	XML Table Element.

_.Library.Status	condsMatch (conds, d, condValExp)
	Check Conditional Matches.

_.Library.Status	createAndOpenFile (file, timeout)
	Create & Open File.

_.Library.String	createOrderByList (orderBy, d)
	Create a valid SQL <order-by-list>

	fileBody (file, format, metadata)
	File Body.

_.Library.Status	fileFooter (file, format, footerMsg, metadata, elapseTime, rowCnt)
	File Footer.

_.Library.Status	fileHeader (file, format, title, class, method, version, metadata, bcFlag)
	File Header.

_.Library.String	getOutputFile (file, className, methodName, format, hDate, tSC)
	Get the 'outputFile'.

_.Library.Status	openFileForRead (file, timeout)
	Open File For Read.

Detailed Description

– DEPRECATED — DEPRECATED — DEPRECATED — DEPRECATED — DEPRECATED –

Starting with ver '2.0' of the PTools application, this class is considered to be DEPRECATED and is replaced by the <class>SYS.PTools.StatsSQL</class> class.

This class is still usable under extreme circumstances when invoking the 'SetSQLStatsSaveFlag()' method and passing to the (saveType) parameter the following value: 2 = Original (backward-compatible)

– DEPRECATED — DEPRECATED — DEPRECATED — DEPRECATED — DEPRECATED –

Class: SYS.PTools.SQLQuery Replaced By: <class>SYS.PTools.StatsSQL</class> Purpose:
This is the parent class of <class>SYS.PTools.SQLStats</class>.
This class is used to store the the following general info of a query from compile time: <property>QueryText</property>, <property>QueryType</property>, <property>CursorName</property>, <property>RoutineName</property>, & <property>NameSpace</property>.

All of the run time data is stored in the <class>SYS.PTools.SQLStats</class> class. Error information is stored in the following error global:

^sqlcq(NAMESPACE,"PTools","Error",[...])=$LIST Info

Member Function Documentation

◆ Export()

_.Library.String Export	(	file,
		delim,
		exportPlan
	)

static

<DEP> – DEPRECATED — DEPRECATED — DEPRECATED — DEPRECATED — DEPRECATED – </DEP> Method: Export [SQL: SQLQuery_Export] Replaces By: Export SQL: StatsSQL_Export Status: <BC>Maintained for Backward-Compatibility</BC> See exportSQLQuery(...) Purpose: This method generates a comma delimited file containing the data from the 'SYS.PTools.SQLQuery' class

Invocation: This method can be invoked in the following ways: ObjectScript: ##class(SYS.PTools.SQLQuery).Export(...) SQL: CALL SYS_PTools.SQLQuery_Export(...) SELECT SYS_PTools.SQLQuery_Export(...)

NOTE: This 'SqlProc' method can be invoked with either the CALL-interface or the SELECT-interface. Both interfaces execute the method: the CALL-interface does not return any resulting value, while the SELECT-interface does.

Examples: The following examples shows the use of this method:

#1 Display this export file to the screen via a InterSystems IRIS Terminal:

       set io=##class(%SYS.PTools.SQLQuery).Export($IO)

#2 Display this export file via the SQL Query Page of the Management Portal:

CALL SYS_PTools.SQLQuery_Export('$IO')

Where: '$IO' = Output to the current device NOTE: '$IO' can be omitted, as it is the default 'file' when invoked via the CALL interface

Data Storage: ^sqlcq($NAMESPACE,"PTools","RunTime","SQLQuery{C|D|I|S|Z}")

Parameters: file - The path and file in which to create and store the data from the SYS_PTools.SQLQuery class/table: (e.g. C:\exportFile.txt) NOTE: $IO = Outputs the data to the screen '$IO' = Output the data to the current device when invoked from the CALL/SELECT-interface '$DEF' = Ouput the data to the DEFAULT file when invoked from the CALL/SELECT-interface [DEFAULT: {MGR-Directory}computerName}_{ConfigName}_YYYYMMDD_HHMMSS_SQLQuery.psql] delim - The delimiter by which to delimit the data of the exported file [DEFAULT: $C(9) // TAB] exportPlan - 0 - Export the SQL Query Text [DEFAULT] 1 - Export the SQL Query Plan

RETURN Value: The output locations of the exported data; Otherwise, return
the error status if one occurred

◆ clearSQLQuery()

_.Library.Status clearSQLQuery	(	_.Library.String	ns,
		_.Library.String	rtn,
		_.Library.Integer	ph3,
		_.Library.Integer	clearErrs,
		_.Library.Integer	returnType,
		_.Library.RawString	ptInfo
	)

static

Method: clearSQLQuery [SQL: PT_clearSQLQuery] Replaced BY: N/A Status: New Functionality Purpose: Delete all of the data stored in the 'SYS.PTools.SQLQuery' class, based on the specified parameters...

Invocation: This method can be invoked in the following ways: ObjectScript: ##class(SYS.PTools.SQLQuery).clearSQLQuery(...) SQL: CALL SYS_PTools.PT_clearSQLQuery(...) SELECT SYS_PTools.PT_clearSQLQuery(...)

NOTE: This 'SqlProc' method can be invoked with either the CALL-interface or the SELECT-interface. Both interfaces execute the method: the CALL-interface does not return any resulting value, while the SELECT-interface does.

Examples: The following examples shows the use of this method:

#1 Delete all of the data stored in the 'SYS.PTools.SQLQuery' class in the 'SAMPLES' namespace:

set stats=##class(SYS.PTools.SQLQuery).clearSQLQuery("SAMPLES")

Data Storage: ^sqlcq($NAMESPACE,"PTools","RunTime","SQLQuery{C|D|I|S|Z}")

Parameters: ns - The namespace in which to clear SQLQuery data If none provided, use the current namespaces where SQLQuery data collected [DEFAULT: Current Namespace] rtn - The routine for which to clear SQLQuery data If none provided, clear all routines in the given 'ns' [OPTIONAL] ph3 - Placeholder Parameter for future extensibility clearErrs - 0 = Don't delete the 'PTools' Application Errors 1 = Delete all of the 'PTools' Application Errors [DEFAULT: 0] returnType - 0 = Return a Status code of either $$$OK or $$$ERROR() 1 = Return the number of Stats rows deleted from the following class: SYS.PTools.SQLQuery [DEFAULT: 0] ptInfo - A Pass By Reference information array that returns detailed information to the user in the following format: ptInfo(category,variable)=value OR $LB(val1,...,valn) Where category = { "cnt" | "curr" | "term" | ... } variable = A var corresponding to the given 'category'

Example: ptInfo("cnt","clearSQLQuery")=The number of rows deleted via this method [Routine Method] ptInfo("cnt","purgeSQLQuery")=The number of rows deleted via this method [Class Method]

RETURN Value: Based on the value of the 'returnType' parameter, return one of the following: 0: Return a Status code of either $$$OK or $$$ERROR()

1: Return the number of Stats rows deleted from the following class; Otherwise, return an error message if an error occurred: SYS.PTools.SQLQuery

◆ exportSQLQuery()

_.Library.Status exportSQLQuery	(		file,
			format,
			silent,
			exportPlan,
		_.Library.RawString	conds,
		_.Library.RawString	ptInfo,
			bcFlag
	)

static

Method: exportSQLQuery [SQL: PT_exportSQLQuery] Replaces: Export [SQL: SQLQuery_Export] <DEP>[DEPRECATED]</DEP> Replaced By: exportStatsSQL SQL: PT_exportStatsSQL Status: New Method to replicate Backward-Compatible Method it 'Replaces' Purpose: Create a Performance Tool file containing the data from the 'SYS.PTools.SQLQuery' and return the output location... By default, the file will be created in the current directory of the InterSystems IRIS instance.

NOTE: Current directory can be obtained in the following way, from a InterSystems IRIS Terminal: >write $ZU(12,"")

You can pass a different value for the 'file' parameters if you wish to override the default location and file name.

Invocation: This method can be invoked in the following ways: ObjectScript: ##class(SYS.PTools.SQLQuery).exportSQLQuery(...) SQL: CALL SYS_PTools.PT_exportSQLQuery(...) SELECT SYS_PTools.PT_exportSQLQuery(...)

NOTE: This 'SqlProc' method can be invoked with either the CALL-interface or the SELECT-interface. Both interfaces execute the method: the CALL-interface does not return any resulting value, while the SELECT-interface does.

Examples: The following examples shows the use of this method:

#1 Display this export file to the screen via a InterSystems IRIS Terminal:

       set tSC=##class(%SYS.PTools.SQLQuery).exportSQLQuery($IO)

#2 Display this export file via the SQL Query Page of the Management Portal:

CALL SYS_PTools.PT_exportSQLQuery('$IO','H')

Where: '$IO' = Output to the current device NOTE: '$IO' can be omitted, as it is the default 'file' when invoked via the CALL interface 'H' = Output the format in HTML format NOTE: 'H' can be omitted, as it is the default 'format' when invoked via the CALL interface

Data Storage: ^sqlcq($NAMESPACE,"PTools","RunTime","SQLStats{C|D|I|S|Z}")

Parameters: file - The path and file in which to create and store the data from the SYS_PTools.SQLQuery class: (e.g. C:exportFile.txt) NOTE: $IO = Outputs the data to the screen '$IO' = Output the data to the current device when invoked from the CALL/SELECT-interface '$DEF' = Ouput the data to the DEFAULT file when invoked from the CALL/SELECT-interface [DEFAULT: {Current-Directory}\PT_SQLQuery_exportSQLQuery_YYYYMMDD_HHMMSS.{ext}] WHERE {Current-Directory} = The directory of the Namespace in which this method is invoked (e.g. $ZU(12,"")) NOTE 2: If Passed By Reference, then 'file' will be returned as the canonical name of the Export/Reporting file format - The output format of the Export/Reporting file This parameter has the following structure of constituent elements: format=<data-format>[:$LB(<delim>,<csv-header>,<csv-footer>)] Where the constituent elements have the following values: <data-format> - The format of the Export/Reporting file:

P = Printable/Viewable report file (.txt file, no pagination)
D = Comma-delimited data file (.csv file) which can be read into a spreadsheet
X = Microsoft Excel XML markup file suitable for import into Excel (.xml file)
H = HTML page file (.html file)
Z = User-defined delimiter "P" formatted file (.dlm file) NOTE: The <delim> element is required or defaulted to $C(9) (TAB) Optional Elements: <delim> - User-defined delimiter [DEFAULT: $C(9) (TAB)] NOTE: This is generally used for <data-format>="Z" <csv-header> - .csv file header for <data-format>="D":
0 = Don't add non-standard information header to file [DEFAULT]
1 = Add non-standard information header to file <csv-footer> - .csv file footer for <data-format>="D":
0 = Don't add non-standard information footer to file [DEFAULT]
1 = Add non-standard information footer to file EXAMPLES: Valid 'format' values:
"H" // HTML file
"D" // CSV file with No information header or footer
"D:"_$LB(,1,1) // CSV file with information header & footer
"Z:"_$LB("^") // User-defined delimiter file (delim="^") silent - 0 - Display all messages during the running of this method 1 - Don't display any messages during the running of this method exportPlan - 0 - Export the SQL Query Text [DEFAULT] 1 - Export the SQL Query Plan conds - A string/array of possible conditions by which to restrict the output of the Export file, in the following format:

conds=<full condition> OR conds(0)=pos Count (WHERE pos = {1...n}) conds(pos)=$LIST() Pieces: 1) [<logical operator>] (Assumed Default: &&) 2) [{Heading}] (Omit for override cond) 3) <simple condition> | <complex condition>

WHERE: <full condition> := <full condition expression> <logical operator> := {&& | ||} (&& = AND | || = OR) <simple condition>@* := <oper>

@ = Contains no references to {Heading}

= Contains no references to {*}

EXAMPLE: <full condition> conds="("",INFO,MAIN,""[("",""_{Module}_"",""))||({GlobalRefs}>20)" <simple condition> conds(0)=3 conds(1)=$LB(,"Module","=""INFO""") conds(2)=$LB("||","Module","=""MAIN""") conds(3)=$LB("||","GlobalRefs",">20") <complex condition> conds(0)=2 conds(1)=$LB(,"Module",""",INFO,MAIN,""[("",""_{*}_"","")") conds(2)=$LB("||","GlobalRefs","{*}>20") WHERE: {*} = value substitution for the 'Module' & 'GlobalRefs' fields NOTE: Conditions that don't contain any references to {Heading} fields, often called <override condition>s, can be included as <complex condition>s, as in the following example: conds(pos)=$LB(,,"$g(^zAction(""runIt""))=1")

NOTE: All conditions must be satisfied for the conds() to be considered true and for the row to be exported [PASS BY REFERENCE] ptInfo - A Pass By Reference information array that returns to the user the following details: ptInfo(variable)=value ptInfo("outputFile")=The canonical name of the Export/Reporting file bcFlag - This is a Backward-Compatibility flag used for [Internal Purposes ONLY]

RETURN Value: The status from the invocation of this method

◆ purgeSQLQuery()

_.Library.Status purgeSQLQuery	(	_.Library.String	ns,
		_.Library.String	rtn,
		_.Library.Integer	ph3,
		_.Library.Integer	clearErrs,
		_.Library.Integer	returnType,
		_.Library.RawString	ptInfo
	)

static

Entry Point providing new functionality to delete Backward-compatible data:

NOTE: See the <method>clearSQLQuery</method> method above for more details.

Member Data Documentation

◆ CompileTime

CompileTime

Number of Seconds it takes to compile the query.

◆ CursorName

CursorName

What is the name of the cursor for this SQL Statement.

◆ Hash

Hash

hash the SQL so we can match incoming SQL with already stored Stats

◆ ImportSchema

ImportSchema

ImportSchema is used in generated code to handle sql statements that have unqualified table names.

◆ InternalQueryText

InternalQueryText

◆ NameSpace

NameSpace

What NameSpace the SQL was generated in.

◆ QueryText

QueryText

Store the first 15000 charactors of the SQL Query in this field.

◆ QueryType

QueryType

Is the Query an INSERT UPDATE DELETE or SELECT query.

◆ RoutineName

RoutineName

What Routine is the SQL generated in.

◆ RunCount

RunCount

Number of times this query has be executed.

◆ SQLIndexHash

SQLIndexHash

Internal unique statement hash used as the ID for the SQL Statement Index.

◆ SQLStatsPointer

SQLStatsPointer

◆ details

details

Do we have level 3 stats for this query.
