Dynamic parameters for the running system. More...
Public Member Functions | |
| def | __init__ (self) |
| Dynamic parameters for the running system. More... | |
Public Attributes | |
| DefaultGlobalSelectionMask | |
| Default value for <property>GlobalSelectionMask</property> for databases. More... | |
| GlobalSelectionMask | |
| An array of strings used to determine the set of global names to check. More... | |
| MinimumQuerySize | |
| The minimum number of nodes to traverse in a query. More... | |
| SystemName | |
| Name of the DataCheck Destination system that uses this object. More... | |
| Throttle | |
| An integer between 1 and 10 to control how much of the system. More... | |
| UseGlobalSelectionMask | |
| If true use the per-database selection mask defined in the. More... | |
| UseGlobalSelectionRangeLists | |
| If true use the RangeList objects from the set of Global Selection RangeLists. More... | |
Dynamic parameters for the running system.
An instance of this class is referenced by each <CLASS>Destination</CLASS> and affects the behavior of both systems involved in the check. The RunParameters object defines the performance characteristics and what to check. Changes that are saved while the system is running will take immediate effect unless otherwise specified.
| def __init__ | ( | self | ) |
Dynamic parameters for the running system.
An instance of this class is referenced by each <CLASS>Destination</CLASS> and affects the behavior of both systems involved in the check. The RunParameters object defines the performance characteristics and what to check. Changes that are saved while the system is running will take immediate effect unless otherwise specified.
| DefaultGlobalSelectionMask |
Default value for <property>GlobalSelectionMask</property> for databases.
not defined in that array. Applies only when UseGlobalSelectionMask is true.
Changes take effect next time a new check is begun (ie on entering the 'Check' phase).
| GlobalSelectionMask |
An array of strings used to determine the set of global names to check.
in each database. It is keyed by <CLASS>LocalDatabase</CLASS>, which is the local database path for non-mirror DataCheck configurations and the mirror database name for mirrored DataCheck configurations. Keys should be normalized using ##class(SYS.DataCheck.LocalDatabase).Normalize() before being inserted. The value is a mask, or comma-separated list of masks, to select globals. If the value is not defined for a database, it defaults to select all globals.
IMPORTANT: Callers that modify this array are responsible for ensuring that the database is specified correctly, and for non-mirror DataCheck configurations, that it has a mapping specified in the DataCheck configuration.
Example masks are as follows:
ABC* - All strings starting with ABC
A:D - All strings between A and D
A:D,Y* - All strings between A and D, and all strings starting with Y
A:D,'C* - All strings between A and D, except those starting with C
Changes take effect next time a new check is begun (ie on entering the 'Check' phase).
| MinimumQuerySize |
The minimum number of nodes to traverse in a query.
This is the granularity,
in number of global nodes, with which the system will isolate discrepant global ranges. A value of 1 means that the system will isolate discrepancies down to a single node. Higher values give vastly better performance through unmatched sections.
Name of the DataCheck Destination system that uses this object.
Set upon creating the destination object and should not be changed.
| Throttle |
An integer between 1 and 10 to control how much of the system.
resources (CPU, disk I/O, database cache) the DataCheck system may use. The implementation may differ over time as software and hardware characteristics evolve. The setting can be changed dynamically to tune DataCheck activity up or down. The characteristics of every system are different, but the following general meanings apply:
A throttle setting of 1 uses no more resources than one process for performing DataCheck queries. In other words, it uses at most one CPU and does only one disk I/O at a time. Whether the resources used are primary CPU or primarily disk I/O depends on whether the data is in buffers already and can vary as the check progresses. As the throttle is raised up to 8, more system resources are consumed at each step. For systems with large amounts of resources (many CPUs, etc), each interval is scaled to increase resource consumption by, very roughly, the
same multiplicative factor, such that at a throttle setting of 8, DataCheck uses a large portion of system resources. This takes into account the number of CPUs and other factors. At a throttle setting of 8 the system is still expected to be responsive to a light load of application activity, and settings of 6, 7, or 8 may be an appropriate on a typical system at off-peak hours (weekends or overnights for example). A throttle setting of 9 is like 8, but allows DataCheck jobs to use the entire buffer pool (unsets the batch flag). A throttle setting of 10 attempts to utilize nearly all system resources for completing the check.
| UseGlobalSelectionMask |
If true use the per-database selection mask defined in the.
<PROPERTY>GlobalSelectionMask</PROPERTY> array to choose which globals to check. If false, check all globals in all directories.
Changes take effect next time a new check is begun (ie on entering the 'Check' phase).
| UseGlobalSelectionRangeLists |
If true use the RangeList objects from the set of Global Selection RangeLists.
to define additional subscript ranges to include/exclude. If false ignore the Global Selection RangeLists
Changes take effect next time a new check is begun (ie on entering the 'Check' phase).
